XCMG official 2 ton mini backhoe wheel loader XC870HK Chinese small backhoe with excavator and loader.
XC870HK is a K series backhoe loader newly launched by XCMG. This product is upgraded on the basis of the mature equipment and technical performances of present products, to further improve the comfort, safety, maintainability, reliability, supportability, and economy of the product.
1. Performance features
* Achieve better traveling stability and realize faster site transfer speed.
* Has high energy-saving, intelligence and efficiency and meet the configuration demands of more attachments.
2. High Strength and High efficiency for Extensive Adaptability
* Has high operation efficiency and good levelness of bucket and rapid operations.
3. Operation Safety and Control Comfort
* Air conditioning system features large space, good sound and heat insulation, and good shock absorption.
* realizes broader visual field and comfortable operations.
| Description | Unit | Parameter value | |
| Outline dimensions(L×W×H) | mm | 6075×2350×3520 | |
| Total weight | kg | 8200 | |
| Max. travel speed | km/h | ≥40 | |
| Wheelbase | mm | 2180 | |
| Engine | Power | kW | 82(Cummins) 74(Cummins) 74.9(Deutz dalian) 70(weichai ) |
| Supplier | tier 3 tier 2 tier 3 tier 2 | ||
| Loading device | Bucket capacity | m³ | 1 |
| Rated load | kg | 2500 | |
| Max. breakout | kN | 66 | |
| Max. discharge height | mm | 2770 | |
| Max. discharge distance | mm | 755 | |
| System pressure | Mpa | 24 | |
| Digging device | Bucket capacity | m³ | 0.25 |
| Max. digging radius | mm | 5420 | |
| Max. digging depth | mm | 4320 | |
| Max. digging force | kN | 63 | |
| System pressure | Mpa | 24 | |
